NetMediator RTD G5 Full Specs

NetMediator-T2S Back Panel

The NetMediator RTD G5 is a RoHS 5/6-compliant, LAN-based, SNMP/DCPx remote telemetry unit. The NetMediator RTD G5 has all the tools you need to manage your remote sites, including built-in alarm monitoring, paging and email capabilities that can eliminate the need for an alarm master.

Find temperature, humidity, and many other
discrete and analog sensors for your DPS RTUs.

Full Specifications
Protocols: SNMP, DCP, TRIP, SNPP, TAP, HTTP, FTP, TELNET, ICMP, RADIUS
Discrete Inputs: 32
Analog Inputs: 8 (Expandable to 72 with DX Expansions)
Analog Input Range: +/-94 to 94 VDC or 4 to 20 mA
Analog Accuracy: +/- 1% of Analog Range
Control Relays: 8 Form C
Max Voltage: 60 VDC/120 VAC
Max Current: 1 Amp, AC/DC
Interface: 9 RJ45 Yost serial ports
2 RJ45 10/100 Ethernet ports
1 RJ11 telco jack
2 50-pin amphenol connectors (discretes, controls, and analogs)
1 4-pin screw connector (analogs)
Visual Interface: 16 bicolor LEDs,
5 unicolor LEDs
LCD display
Dimensions: 1.75"H x 17"W x 12.75"D (4.5 cm x 43.2 cm x 32.4 cm)
Weight: 4 lbs. 3 oz. (1.9 kg)
Mounting: 19" or 23" rack
Power Input: -48 VDC nominal (-36 to -72 VDC)
-24 VDC nominal (-18 to -36 VDC)
Wide Range -24/-48 VDC ( -18 to -72 VDC)
+24VDC (+18 to +36VDC)
Current Draw: 200 mA at 48 VDC
GMT Fuse: 3/4 amp recommended
Operating Temperature: 32 -140 degrees F (0 -60 degrees C)
Operating Humidity: 0%-95% noncondensing

Ordering Options


SiteMON IP

SiteMon IP Surveillance Camera

With this camera and RTU in one, you don't need to wonder what's going on at your sites. Connecting directly to the NetGuardian's optional LAN switch, the new SiteMON IP enables you to make security decisions remotely, allowing you to dispatch on-call staff, security, or even police. Available with or without an outdoor enclosure.

66 block

66 block

A 66 block is a simple way to use wire-wrap connections with DPS RTUs. When telcos really want connections to stay in place, they use wire wrap. You'll simply punch down your alarm, analog, and/or control relay wiring to the 66 block, then connect the 66 block to the RTU using a standard amphenol cable (also available from DPS).

GLD

General LCD Display

The General LCD Display (GLD) allows the user to monitor an existing network from different locations by providing remote visibility of the system's status.

NetMediator RTD DX

NetMediator RTD DX

The NetMediator RTD DX provides an additional 32 analog inputs for your NetMediator RTD G5. You can connect up to two RTD DX models to your RTD G5, bringing total analog coverage to 72 sensors

NetGuardian 3288 Test Fixture

NetGuardian 3288 Test Fixture

Every DPS product is rigorously tested before shipping, and the NetGuardian Test Box allows technicians to verify every discrete alarm input, control relay, and voltage-based analog alarm input on a NetMediator RTD G5. This time-tested tool is now available to you as the NetGuardian 3288 Test Fixture.
