NetGuardian 832A G4: Full Specifications
The NetGuardian 832A monitors 32 discrete alarms and 8 analog alarms, pings 32 network elements, controls 8 relays, provides LAN reach through access to 8 serial ports, and reports via SNMP v2c or DCPX, e-mail, or pagers
| Full Specifications | |
|---|---|
| Protocols: | SNMP v2c and DCPx |
| Discrete Inputs: | 32 (expandable to 80, 128 or 176 see options) |
| Alarm Detection Speed: | User-defined (3 to 999 msec) |
| Analog Inputs: | 8 |
| Analog Input Range: | (-92 to 92 VDC or 4 to 20 mA) |
| Control Outputs: | 8 Form C relay contacts (expandable to 16, 24, 32) |
|
60 VDC/120 VAC |
|
1 Amp, AC/DC |
| IP Address Ping Targets: | 32 |
| Interfaces: | 8 RJ45 YOST standard RS-232 ports (see options) |
| Modem: | 33.6K internal |
| Visual Interface: | LCD display with descriptive text |
| Audible Interface: | Alarm speaker |
| Dimensions: | 1.75"H x 17"W x 12"D (4.5 cm x 43.2 cm x 30.5 cm) |
| Weight: | 4 lbs. 3 oz. (1.9 kg) |
| Mounting: | 19" or 23" rack |
| Power Input: | -48VDC (-40 to -56 VDC) see options (Optional) -24 VDC (-20 to -56 VDC) (Optional) Wide Range -24/-48 VDC (-20 to -56 VDC) |
| Current Draw: | 200mA |
| Fuse: | 3/4 Amp GMT for power inputs 1/4 Amp GMT for external sensor power outputs and integrated Ethernet hub |
| Operating Temperature: | 32°-140° F (0°-60° C) |
| Operating Humidity: | 0%-95% noncondensing |
| RoHS 5 Approved | |
